100G QSFP Active Optical Cables AOC Cable Module RoHS-6 Compliant

100G QSFP Active Optical Cables AOC Cable Module

Features

• Supports 4-channel 25.78125Gbps bi-directional data links
• Compliant with IEEE 802.3
• Compliant with SFF-8636
• Hot-pluggable QSFP footprint
• 850nm VCSEL array laser transmitter
• Built-in digital diagnostic functions
• Up to 100m in length
• Low power consumption (Operating Power <2.0W@Single-end)
• Single power supply 3.3V
• RoHS-6 Compliant
• Operating temperature range (Case Temperature): Commercial Level: 0◦C to 70◦C

Standards

• 100G Ethernet Data Center Intra-Rack and Inter-Rack links

Ordering information

Description

100G active optical cable transceivers are based on 100G Ethernet IEEE 802.3 standard and complies with

SFF-8636 standard, providing fast and reliable interface for 100G Ethernet. It provides four independent transmit

and receive channels, each capable of 25Gbps,with a total bandwidth of 100Gbps, making it a high-performance,

low-power, short-haul interconnect solution.
