10G BIDI LC BOSA T1270R1330 Optical Sub Assembly High Sensitive

Brand Name : Optowix

Model Number : SBA-119-B101

Place of Origin : China

MOQ : 1

Payment Terms : T/T

Supply Ability : 10Kpcs

Delivery Time : 5-8 working days

Packaging Details : ESD plastic case

Product Name : 10G LC BOSA T1270R1330 C temp

SpeedRate : 10G

TX : 10G 1270nm DFB laser

RX : 10G PIN Receiver

Warranty : 12 Months

Interface : LC BIDI

Contact Now

10G BIDI LC BOSA T1270R1330 Optical Sub Assembly
Features
  • DFB uncooled laser diode with isolator
  • High sensitive 10G PIN(APD)/TIA
  • LC receptacle connector
  • RoHS compliant and lead-free
  • Operation case temperature : 0℃ ~ 70℃
Applications
  • Switch to switch interface
  • Gigabit Ethernet Point-to-Point bi-directional transceiver
  • SDH/SONET
Absolute Maximum Ratings
Parameter Symbol Min Max Unit Note
Forward Voltage (LD) V FL 2 V
Forward Current (LD) I FL 120 mA
Reverse Voltage (MPD) V RM 20 V
Forward Current (MPD) I FM 10 mA
Storage Temperature Tstg -40 +85 ℃
Operating Case Temperature Tc 0 +70 ℃
Lead Soldering Temperature (10 sec) TLS - +260 ℃

Electrical/Optical Characteristics (Tc=25℃, unless otherwise specified)

Transmitter
Parameter Symbol Min. Typ. Max. Unit Test Condition
Threshold Current Ith - 8 12 mA Tc=25℃
- 15 30 mA Tc=70℃
Forward Voltage Vf - 1.2 1.5 V CW,Iop=33mA
Fiber Output Power Pf 0.4 0.6 0.8 mW CW,Iop=33mA
Central Wavelength λc 1260 1270 1280 nm CW,Iop=33mA
Spectral Width (RMS) Δλ - - 1 nm CW,Iop=33mA
Tracking Error TE -1.5 - 1.5 dBm Tc=0~70℃
Monitor Current Im 100 - 1000 uA CW, Iop=33mA , Vr=5V
Monitor Dark Current Id - - 100 nA

Vr=5V

Receiver
Parameter Symbol Min. Typ. Max. Unit Test Condition
Supply Voltage Vcc 3 3.3 3.5 V
Supply Current Icc - - 45 mA
Receiver wavelength λ 1320 1330 1340 nm
RSSI Current IRSSI 6.8 7.5 - uA λ=1310nm,P=10uW
Sensitivity Sen. - - -16 dBm 10Gb/s PRBS2^31-1,NRZ,ER=5,BER@10E-12
Overload Pov 0.5 - - dBm
Optical Return Loss ORL - - -27 dB
