Home > Fiber Optical Transceivers >

10G SFP+ DWDM 1528.77~1563.05nm 80km Transceiver Fiber Optic Transceiver Module

Product Categories

Wuhan Optowix Co.,ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: 10G SFP DWDM 152877156305nm 80km Transceiver Fiber Optic Transceiver Module
Brand: Optowix
Price: 1 USD

Brand Name : Optowix

Model Number : MF1H-DWTG-Dxx

Place of Origin : China

MOQ : 1

Payment Terms : T/T

Supply Ability : 10Kpcs

Delivery Time : 5-8 working days

Packaging Details : ESD plastic case

Optowix PN : MF1H-DWTG-Dxx

Product Name : 10.3Gbps SFP+ DWDM Transceiver, Single Mode, 80km Reach, Module

SpeedRate : 10G

Distrance : 80km

Interface : duplex LC

Wavelength : DWDM 1528.77~1563.05nm

Environment : 0ºC ~ 70ºC

Contact Now

10.3Gbps SFP+ DWDM Transceiver, Single Mode, 40km Reach

Features

Supports up to 10.7Gbps bit rates
Hot-pluggable SFP+ footprint
100GHz ITU, C Band DWDM Cooled EML laser and APD photodiode, Up to 80km for SMF transmission
Compliant with SFP+ MSA and SFF-8472 with duplex LC receptacle
Compatible with RoHS
Single +3.3V power supply
Real Time Digital Diagnostic Monitoring
Operating case temperature: Standard: 0 to +70°C

Applications

Standards

Ordering Information

Part Number	Product Description
MF1H-DWTG-Dxx	SFP+ 10G DWDM 1528.77~1563.05nm 80km 0ºC ~ +70ºC,

10G SFP+ DWDM 1528.77~1563.05nm 80km Transceiver Fiber Optic Transceiver Module

Description

The SFP+ transceivers are high performance, cost effective modules supporting data rate of 10Gbps and 40km transmission distance with SMF.
The transceiver consists of three sections: a Cooled EML laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.
The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472 digital diagnostics functions.

Absolute Maximum Ratings

Recommended Operating Conditions

Optical and Electrical Characteristics

10G SFP+ DWDM 1528.77~1563.05nm 80km Transceiver Fiber Optic Transceiver Module Images
